Description
Technical Data
| Reed width | 150,170,190,210,230,260,280,320,340 cm |
| Drive |
New designed motor;Electromagnetic brake;Butt oncontrol
|
| Weft selection | 1,2,4 or 6 colors |
| Weft insertion |
The main and auxiliary nozzles are electronically controlled
|
| Beating |
Solid beating shaft with multiple foot stand, Four crank shedding beating
|
| Let-off | Eletric let off,φ800mm beam pipe |
| Take-up | Electric take up,Max rolling φ600mm |
| Heald frame |
6~16 pcs on low price Tsudakoma tech weaving air jet loom
|
| Shedding |
crank shedding/positive cam shedding/electronic dobby shedding
|
| Air supplying | Centralized air compressor |
| Speed | 500~1000rpm |
| Power | 2.8kw,3.0kw,3.8kw,4.5kw |
| Weft density | 5-60 picks/inch |
| Yarn account | 10-60S |
| Cutting | Mechanical |
| Selvedge | Closed selvedge with tuck-in device |
| Wires | 10000 pieces |
| Dropper | 10000 pieces |
| Reed | 1 piece |
| Back rest |
Double back rest,removable back rest seat on the back of China high speed air jet loom
|
| Electric control box |
Touchable screen;Controlled by computer;parameter setting and controlling,autodiagnosis
|
| Stopping device |
4 color LED lights a,cracked ends:6 line droppers;b, broken picks:two weft feeler c,Leno edge apparatus:near switch;d,Capture side of weft yarn:sensor
|
| Gears in main box | T tooth with QT700 material |
| Belt |
Brand: Sanmen Chunguang, excellent quality, longer life
|
| Gear shaft |
45# steel with High frequency quenching process
|
| Oil seal | CTY GERMANY |
| Oil nipple | Taiwan |
| Crossbeam | Triangular steel, weaving steadily |
| Lifting |
Solid supporting, Thickened pipe,imported bearings
|
| Painting | Polishing, sandblasting, baking finish |
| Iron castings |
Weight of the China high speed air jet loom iron castings are increased
|
